Pneumax RAP' Push-In Fittings are high-quality brass connectors designed for fast, tool-free tube connection and disconnection in pneumatic, vacuum, and low-pressure hydraulic circuits. Manufactured in Italy to ISO standards, they are available in a broad range of models and sizes for integration into diverse automation and industrial systems.
Material: Nickel-plated brass (RAP, RAP-Black, OT variants) with thrust sleeves available in green, blue, black, or grey for easy identification.
Tube Sizes: 4mm to 16mm OD, compatible with TPU (polyurethane), PA11/PA12 (polyamide), and PE tubing.
Thread Connections: M5, M6, M12x1.5, 1/8", 1/4", 3/8", 1/2" BSP parallel or tapered. Models include straight adaptors, elbows, tees, bulkhead connectors, and cartridge fittings.
Operating Pressure: Suitable for compressed air circuits up to 26 bar (at 20°C with PA12 tube), and tested for breaking pressures up to 90 bar depending on tube and fitting size.
Temperature Range: -20°C to +70°C (standard RAP), and up to +80°C for RAP OT, with special models available for higher temperatures.
Seal: O-rings (NBR/Viton/FKM depending on variant) ensure leak-free performance. The brass gripper and thrust sleeve guarantee strong retention and easy release without tools.
Every RAP batch is rigorously tested for leak-tightness, dimensional accuracy, and mechanical resistance at working pressures.
Suitable for pneumatic actuation, automation panels, robotics, vacuum circuits, and low-pressure hydraulic lines. Widely used in automotive, packaging, and general industrial sectors.
The push-in design speeds up installation and maintenance, reducing system downtime and labor costs.
Pneumax 22-08-38 swivel elbow bridges 8mm tubing to G3/8" male ports with full rotational capability for high-volume pneumatic circuits. The pivoti...
View full details
Pneumax 22-08-14 swivel elbow joins 8mm tubing to G1/4" male threaded ports with unrestricted rotational freedom, engineered for high-flow pneumati...
View full details
Pneumax 22-08-18 swivel elbow connects 8mm tubing to G1/8" male ports with full articulation for high-capacity pneumatic systems. The rotating join...
View full details
Pneumax 22-06-14 swivel elbow facilitates connections between 6mm tubing and G1/4" male threaded ports with unrestricted rotational movement. The p...
View full details
Pneumax 22-06-18 swivel elbow connects 6mm tubing to G1/8" male ports with full rotational capability, ideal for medium-flow pneumatic circuits. Th...
View full details
Pneumax 22-06-M5 swivel elbow accommodates 6mm tubing with M5 male threading in a rotating configuration designed for high-flow applications. The a...
View full details
Pneumax 22-04-14 swivel elbow connector joins 4mm tubing to G1/4" male threaded ports with full rotational freedom. The articulated design absorbs ...
View full details
Pneumax 22-04-18 swivel elbow fitting bridges 4mm tubing to G1/8" male ports with articulated precision. The rotating joint minimises hose fatigue ...
View full details
Pneumax 22-04-M5 swivel elbow connector delivers reliable pneumatic connections in compact applications. This parallel fitting accommodates 4mm tub...
View full details
Pneumax 20-10-38 swivel tee connector pairs 10mm push-fit tubing with G3/8" male parallel threading, maximising flow efficiency whilst permitting f...
View full details
Pneumax 20-10-14 swivel tee adapter combines 10mm push-fit tubing with G1/4" male parallel port connection, enabling high-volume flow with unrestri...
View full details
Pneumax 20-08-38 swivel tee fitting interfaces 8mm push-fit tubing with G3/8" male parallel threading, delivering substantial flow capacity with co...
View full details
Pneumax 20-08-14 swivel tee connector joins 8mm push-fit tubing to G1/4" male parallel ports with unrestricted pivoting action for flexible system ...
View full details
Pneumax 20-08-18 swivel tee adapter accommodates 8mm push-fit tubing with G1/8" male parallel threading, maximising flow efficiency whilst permitti...
View full details
Pneumax 20-06-14 swivel tee fitting combines 6mm push-fit tubing with G1/4" male parallel port connection, enabling multi-directional routing in sp...
View full details
Pneumax 20-06-18 swivel tee connector pairs 6mm push-fit tubing with G1/8" male parallel threading, delivering enhanced flow capacity with unrestri...
View full details
Pneumax 20-04-14 swivel tee adapter interfaces 4mm push-fit tubing with G1/4" male parallel threads, offering 360-degree rotational capability for ...
View full details
Pneumax 20-04-18 swivel tee fitting connects 4mm push-fit tubing to G1/8" male parallel ports with unrestricted rotational movement. The green coll...
View full details
Pneumax 20-04-M5 swivel tee connector combines 4mm push-fit tubing with M5 male parallel threads in a single compact fitting. The green collet secu...
View full details
The Pneumax 10-14-00 is a premium bulkhead fitting designed for 14mm pneumatic tubing with integrated green collet technology. This component deliv...
View full details
The Pneumax 10-12-00 is a heavy-capacity bulkhead fitting engineered for 12mm pneumatic tubing with integrated green collet system. This component ...
View full details
The Pneumax 10-10-00 is a premium bulkhead fitting designed for 10mm pneumatic tubing with integrated green collet retention technology. This compo...
View full details
The Pneumax 10-08-00 is a heavy-duty bulkhead fitting engineered for 8mm pneumatic tubing with integrated green collet system. This component enabl...
View full details
The Pneumax 10-06-00 is a robust bulkhead fitting designed for 6mm pneumatic tubing with integrated green collet technology. This component provide...
View full details
