Metalwork - 5111002 Micro Pressure Regulator 1/8 0-4 Bar

The Metalwork 5111002 BIT Series Micro Pressure Regulator provides precision control for industrial pneumatic systems. Designed with a 1/8 inch threaded port and a 0-4 bar regulation range, this compact unit features a rolling diaphragm to maintain preset pressure stability despite upstream fluctuations. The BIT FC version includes a controlled relief mechanism, allowing for higher regulation accuracy through a slight, continuous air bleed.

Key Features: - Port Size: 1/8 inch Cylindrical Gas
- Regulation Range: 0-4 Bar
- Max Input Pressure: 13 Bar (1.3 MPa)
- Flow Rate: 600 Nl/min at 6.3 bar
- Temperature Range: -10°C to 50°C
- Series: BIT Series (FC Controlled Relief)
- Compact, modular technopolymer body for easy installation
