Metalwork - 5611R161 Syntesi SY1 Pressure Regulator 1/8 0-12 Bar

The Metalwork 5611R161 Syntesi SY1 Pressure Regulator offers high-performance air treatment in a compact, modular design. Engineered with a rolling diaphragm, it ensures maximum precision, reduced friction, and a higher flow rate than standard units. The technopolymer body and nickel-plated brass terminals provide excellent corrosion resistance.

Key Features & Benefits: - Stable pressure regulation even with varying upstream pressure
- Integrated compensation system for enhanced accuracy
- Quick downstream pressure relief (relieving valve)
- Padlockable push-lock knob to prevent tampering
- Compact SY1 size saves space in industrial installationsTechnical Specifications: - Connection: 1/8 BSPP
- Regulation Range: 0-12 Bar
- Max Inlet Pressure: 15 Bar
- Flow Rate (at 6.3 bar, ΔP 1 bar): 1200 Nl/min
- Temperature Range: -10°C to +50°C
- Pressure Gauge Port: 1/8
