Metalwork - 5620L100 Syntesi Sy2 Lubricator Without Bushing

The Metalwork Syntesi SY2 Lubricator (5620L100) is a modular air-treatment unit designed for efficient actuator lubrication. This size 2 model features a compact, lightweight technopolymer body and a high-flow design. It uses a flexible diaphragm to create a pressure drop that draws oil from the 130cm³ bowl through a transparent dome for easy metering.

Key Features: - Series: Syntesi SY2
- Type: Lubricator without bushing
- Max Pressure: 13 bar (188 psi)
- Temperature Range: -10°C to +50°C
- Bowl Capacity: 130cm³
- Fluid: Compressed air or inert gases
- Mounting: Vertical
- Additional 1/4 inch ports for gauges or air take-off
