Metalwork - 5620V300 Syntesi Sy2 V3V 3-Way Valve CNOMO Assembly No Bushing

The Metalwork 5620V300 Syntesi Sy2 V3V 3-Way Valve is a robust shut-off device designed to isolate compressed air circuits from the main supply. This size 2 valve effectively relieves the downstream system when closed, making it essential for safe maintenance and machine control. Featuring a CNOMO electro-pneumatic assembly, it provides reliable performance in a compact, modular design that integrates seamlessly with other Syntesi units without the need for additional brackets.

Key Features: - 3-way valve for effective downstream relief
- Modular Syntesi Sy2 series design
- CNOMO electro-pneumatic control
- High flow rate with low pressure drop
- Robust technopolymer body with nickel-plated brass bushings
- Suitable for compressed air and inert gases
- Maximum input pressure: 13 bar (188 psi)
- Temperature range: -10 to 50 degrees Celsius
