Metalwork - 5623V103 Syntesi Sy2 3/8 V3V Manual Valve

The Metalwork 5623V103 Syntesi SY2 is a high-performance 3/8 manual shut-off valve designed to isolate compressed air circuits from the main supply. This 3-way valve ensures safety by relieving downstream pressure in the closed position, making it ideal for maintenance and equipment protection. Part of the modular Syntesi line, it offers exceptional flow rates in a compact, corrosion-resistant technopolymer body.

Key Features: - Manual 3-way shut-off and relief function
- Integrated padlockable knob for lockout/tagout safety
- High flow capacity in a space-saving design
- Front and rear 1/4 auxiliary ports for gaugesSpecifications: - Series: Syntesi (Size 2)
- Port Size: 3/8 BSP
- Max Inlet Pressure: 13 Bar (188 psi)
- Flow Rate: 3600 Nl/min at 1 bar delta P
- Temperature Range: -10 to +50 degrees Celsius
