Metalwork - 5626V206 Syntesi Sy2 1" V3V Pneumatic Valve

The Metalwork 5626V206 Syntesi Sy2 1 inch V3V Pneumatic Valve is a robust 3-way shut-off valve designed to isolate compressed air circuits for maintenance or safety. Part of the modular Syntesi Series, this size 2 valve provides high flow performance in a space-saving technopolymer body. Its pneumatic control allows for seamless integration into automated systems.

Key Features: - Function: 3-way pneumatic shut-off valve (V3V)
- Connection Size: 1 inch threaded inlet/outlet
- Modular Design: Easily integrates with other Syntesi Sy2 units
- Safety: Relieves downstream pressure in the closed position
- Durability: Corrosion-resistant technopolymer and nickel-plated brassSpecifications: - Part Number: 5626V206
- Body Size: Syntesi Size 2
- Max Input Pressure: 13 bar (188 psi)
- Pilot Pressure: 3 to 10 bar
- Flow Rate at 6.3 bar: 4000 Nl/min
- Discharge Flow: 2000 Nl/min
- Temperature Range: -10 to +50 degrees Celsius
