Metalwork - 7010001000 S70 1/8 5/3 90° Lever/Spring Closed Center Valve

The Metalwork 7010001000 is a rugged Series 70 manual lever valve designed for precise control in pneumatic systems. Featuring a 90-degree angular lever and a 5/3 closed-center configuration, it allows for the controlled movement and intermediate stopping of double-acting cylinders. The spring-return mechanism ensures the valve automatically reverts to the closed-center position when the lever is released, maintaining system safety and position.

Key Specifications: - Brand: Metal Work Pneumatic
- Series: 70 Series
- Part Number: 7010001000
- Function: 5-way, 3-position (5/3)
- Center Type: Closed Center
- Actuation: 90° Hand Lever
- Return Type: Spring Return
- Port Size: 1/8 inch BSP
- Flow Rate: 550 Nl/min at 6 bar
- Working Pressure: Vacuum to 10 bar
