SMC ZKJ07C6HV-E5U-T2-R, ZKJ – Vacuum Ejector for Fieldbus System

The ZKJ series is a single energy-saving generator unit with reduced air consumption with a valve and pressure sensor., Nominal Nozzle Size: 07 (ø0.7)
Vacuum Port (V), Supply Port (P): C6 (Metric; Vacuum Port: ø6; Supply Port: Plug)
Exhaust: H (High-noise Reduction Silencer Exhaust)
Exhaust Sealing Valve: V (Exhaust Sealing Valve)
Combination of Supply and Release Valve: E (Supply Valve: N.O.; Release Valve: N.C.)
Rated voltage: 5 (24VDC)
Light/surge voltage suppressor: U (Light: Yes; Surge Voltage Suppressor: Yes; Common Spec: Non-polar)
Pressure sensor: T2 (-100 to 200 KPa)
Option: R (with Manual Override for Residual Pressure Release)
